SensoPart FT 18-2 RM-NS-K4 Photoelectric diffuse sensor
Sensopart
The SensoPart FT 18-2 RM-NS-K4 Photoelectric Diffuse Sensor is engineered for high precision and reliability in demanding environments. It features a durable metal threaded housing and utilizes a red LED light source to ensure accurate detection within a range of 0 to 400 mm. With an NPN switching output and a rapid response time of 1000 Hz, this sensor is designed for fast-paced industrial applications. Installation is simplified with a 2-meter, 4-wire cable connection, and the sensor is built to endure harsh conditions, boasting an IP 67 enclosure rating and a temperature tolerance from -25 to +55 °C. The integrated potentiometer allows for precise adjustments to meet specific application requirements. Comprehensive resources, including datasheets, catalogs, operating instructions, and CAD files, are available for further technical details. Ideal for applications that demand dependable and precise object detection across various industrial settings.
- Sensor principle:
- Photoelectric diffuse sensor
- Series:
- M18
- Working distance min. [mm]:
- 0
- Working distance max. [mm]:
- 400
- Velocity [Hz]:
- 1000
- Adjustment:
- Potentiometer
- Light source:
- LED, red
- Switching output:
- NPN
- Temperature range [°C]:
- -25 ... +55
- Connection type:
- Cable, 4-wire, 2 m
- Enclosure rating:
- IP 67
- Datasheet:
- View
- Catalog:
- View
- Operating Instructions:
- View
- CAD:
- View
