SensoPart IDT 3-S-B2-PSL-KM3 Inductive sensor Ø 3 mm / standard switching distance
Sensopart
The SensoPart IDT 3-S-B2-PSL-KM3 is a compact inductive sensor designed for precision and reliability. With a 3 mm housing and a standard switching distance, this sensor is perfect for applications requiring accurate detection in tight spaces. It features a flush design with a sensing distance (Sn) of 1 mm, ensuring optimal performance. The sensor operates with a PNP/NO output and is equipped with a 200 mm pig tail leading to an M8 3-pin plug, facilitating easy connectivity. Additionally, it supports IO-Link 1.1, offering various parameterization options for enhanced flexibility and integration into modern automation systems.
- Rated operating distance Sn [mm]:
- 1
- Repeatability [mm]:
- 0.02
- Interface:
- IO-Link
- Velocity [Hz]:
- ? 3000
- Mounting:
- Flush
- Housing:
- Stainless steel
- Series:
- ø 3 mm
- Type:
- Barrel type
- Switching output:
- PNP
- Temperature range [°C]:
- -25 ... +70
- Connection type:
- Metal plug M8, 3-pin
- Enclosure rating:
- IP 67
