SMC 22-CDM2B20TN-50Z | Copper/Fluorine/Silicon-Free Air Cylinder CM2 Series 20mm Bore 50mm Stroke TN Non-Rotating
SMC
$102.70
The SMC 22-CDM2B20TN-50Z is a copper, fluorine, and silicon-free air cylinder from the CM2 series with TN non-rotating feature. Part number decoded: CDM2 = CM2 double acting, B = basic type, 20 = 20mm bore, TN = non-rotating, 50 = 50mm stroke, Z = auto-switch groove. The 22- prefix designates a Cu/F/Si-free grade variant.
The CM2 stainless steel mini cylinder with TN non-rotating provides guided actuation with the highest material purity standard. At 20mm bore with 50mm stroke, this generates approximately 19N at 0.6 MPa through a precision-guided, non-rotating path. The 22- prefix ensures all materials in the air path are free of copper, fluorine, and silicon for the most demanding semiconductor front-end applications.
The 22-CDM2B20TN-50Z provides Cu/F/Si-free TN non-rotating CM2 actuation. For the standard clean room CM2 (11-), the 11-CDM2G20-50Z provides the base clean room option. For Cu/F/Si-free compact guided cylinders, the 21-MGPL16-10Z provides the MGPL platform. For Cu/F/Si-free CQS guided compacts, the 21-CDQSB25-30DM provides the CQS option. The Z groove accepts auto switches. RoHS compliant.
- Series:
- 22-CM2-Z (Cu/F/Si-Free)
- Cylinder Type:
- Stainless Mini Round
- Action:
- Double-Acting
- Rod:
- Single Rod
- Bore:
- 20mm
- Stroke:
- 50mm
- Feature:
- TN Non-Rotating
- Material:
- Copper Fluorine Silicon Free
- Auto-Switch:
- Compatible (Z Groove)
- Certifications:
- RoHS
