SMC 25A-CDQ2A80-250DCMZ-M9NL;Secondary Battery Compatible Compact Cylinder CQ2 Series 80mm Bore 250mm Stroke DCM Cushion Heavy-Duty NPN Auto-Switch
SMC
$632.70
The SMC 25A-CDQ2A80-250DCMZ-M9NL is a secondary battery compatible compact cylinder with the large 80mm bore and 250mm extra-long stroke, providing heavy-duty force through maximum travel. Part number decoded: CDQ2 = CQ2 double acting, A = A-type, 80 = 80mm bore, 250 = 250mm stroke, DCM = cushion with M modification, Z = auto-switch groove, M9NL = pre-mounted NPN auto-switch.
At 80mm bore the CQ2 generates approximately 301N at 0.6 MPa through a full 250mm DCM-cushioned stroke one of the highest force-and-travel combinations in the A-type CQ2 range. The DCM cushion is critical at this extreme force and stroke to manage substantial piston kinetic energy. The M9NL switch confirms position over the long travel distance for reliable PLC sequencing.
Designed for battery pack structural frame pressing and holding, large-format module stack compression exceeding 200mm height, formation press platens for tall multi-cell stacks, electrode jumbo-roll transfer mechanisms, and pack-level cooling plate insertion tooling. Choose the 80mm bore 250mm stroke for the heaviest compact actuation requirements in secondary battery production. For shorter stroke at 80mm, the CDQ2A80-50DCMZ provides 50mm and the CDQ2A80-75DMZ provides 75mm. For even higher force, the B-type CDQ2B100, CDQ2B125, CDQ2B140, CDQ2B160, and CDQ2B200 provide 100mm to 200mm bores. RoHS compliant.
- Series:
- 25A-CQ2 (Secondary Battery)
- Cylinder Type:
- Compact
- Action:
- Double-Acting
- Mount:
- A-Type
- Bore:
- 80mm
- Stroke:
- 250mm
- Options:
- DCM (Cushion + Modification)
- Auto-Switch:
- M9NL Pre-Mounted (NPN)
- Operating Pressure:
- 0.05-1.0 MPa
- Application:
- Secondary Battery Manufacturing
- Certifications:
- RoHS
