SMC ITV2030-022L3-X26 ITV1000/2000 Series Electro-pneumatic Regulator Manifold Type Single Unit
SMC
$406.65
The SMC ITV2030-022L3-X26 is a high-performance electro-pneumatic regulator designed for precise air pressure control in industrial applications. This single unit from the ITV1000/2000 Series offers stepless control of air pressure in direct proportion to electric signals, ensuring optimal performance and efficiency. With a sensitivity of 0.2 kPa and a linearity of ±1% or less (F.S.), it guarantees accurate and reliable operation. The regulator also features a hysteresis of 0.5% or less (F.S.), minimizing any deviation in performance. It supports multiple communication protocols, including CC-Link, DeviceNetTM, PROFIBUS DP, and RS-232C, providing versatile connectivity options for seamless integration into existing systems. Ideal for applications requiring precise pressure regulation, this unit is engineered to deliver consistent results in demanding environments.
- Type:
- 2000 type
- Pressure Range:
- 0.5 MPa
- Power Supply Voltage:
- 24 VDC
- Input Signal:
- Current Type 4 To 20 Ma DC (Sink Type)
- Monitor Output:
- Switch Output/NPN Output
- Port Size:
- 1/4
- Cable connector:
- Right angle type 3 m
- Pressure display unit:
- bar
- Made To Order:
- For Manifold
