SMC KQ2E05-00A1 One-Touch Fitting Pack of 10
- SKU:
- KQ2E05-00A1
- Condition:
- New
- Model:
- E (Bulkhead Union, Bulkhead Connector)
- Applicable Tubing O.D.:
- 05 (3/16")
- Pipe Connection Dia.:
- 00 (Same Dia. as Tube)
- Screw Material, Surface Treatment:
- A (Brass)
- Sealant:
- None
- Release Button:
- 1 (Oval Type)
- Made to Order:
- None
Description
KQ2, One-touch Fitting, Inch Size Tube, M, R Connection Thread
KQ2 one-touch, metric and inch size fittings are available in a wide variety of sizes, body styles and thread types. The use of a special profile seal allows the KQ2 to be used for a wide range of pressures from a low vacuum up to a pressure of 1MPa. The KQ2 release collar releases both the chuck and collet to provide a low disconnection force for easy removal of the tubing.
- Tubing material: FEP, PFA, nylon, soft nylon, polyurethane- Fluid: air, water
- Operating pressure range: -100kPa~1MPa
- Release collar allows easy removal of tubing without causing damage to the tube
- This product is not intended for use in potable water systems
-
