SMC LEHF32K2-64-R5C918 belt drive 2-finger electric gripper

SMC LEHF32K2-64-R5C918 LEHF Series Electric Gripper 2-Finger Type Step Motor (Servo 24 VDC) Applicable To The JXC Series

SMC
SKU:
LEHF32K2-64-R5C918
$1,960.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description

LEHF Series Electric Gripper 2-Finger Type Step Motor (Servo 24 VDC) Applicable To The JXC Series

  • Easy setting: Data can be set with only 2 items, position and force; The controller is already set with the data of the actuator; (The actuator and controller are provided as a set.);
  • Equipped with a drop prevention function; (All series come equipped with a self-lock mechanism.);
  • The self-lock mechanism reduces power consumption;
  • Equipped with a gripping check function;
  • It is possible to set the position, speed, and force. (64 points);
  • Compatible controllers: JXC51, JXC61, JXCE1, JXC91, JXCP1, JXCD1, JXCL1, JXCM1, LECP1, LECPA, LECP6(Manufacture Discontinued), LECPMJ(Manufacture Discontinued)
    • Additional Information
    Size:
    32
    Lead:
    Basic Type
    Type:
    2-finger Type
    Stroke:
    Stroke 64 mm
    Motor Cable Entry:
    Basic (Entry On The Right Side)
    Actuator Cable Type/Length:
    Robotic Cable 5 m
    Communication Protocol:
    EtherNet/IP
    Number Of Axes/Special Specification:
    Number Of Axis:For Single Axis Specification:Standard
    Mounting:
    DIN Rail Mounting
    Communication Plug Connector I/O Cable:
    Without Plug Connector
