SMC VFS4100-5FZ-04T 4/5 Port Solenoid Valve
- SKU:
- VFS4100-5FZ-04T
- Condition:
- New
- Availability:
- In stock: 69
- Function:
- 2 Position Single
- Body Option:
- Base Mounted Plug-in
- Direct Manual Override:
- Standard
- Pilot:
- Internal Pilot
- Voltage:
- 24VDC
- Lead Wire:
- Plug-in
- Surge Suppressor:
- Light & Surge Suppressor
- Manual Override:
- Flush
- Piping:
- Or None in Case of w/o Subplate
- Port Size:
- Sub-plate Plug-in Terminal 1/2, Non Plug-in Standard 1/2
- Thread:
- NPTF
Description
VFS4000, Base Mounted Valve, Plug-in & Non Plug-in
Series VFS consists of 5 port pilot solenoid valves with metal seals and base mounted or body ported type manifolds. Base mounted manifolds are available in plug-in and non plug-in styles. Body ported manifolds are available with bar or separate type manifold bases. Port sizes range from 1/8 to 3/4 with Rc(PT), NPTF G(PF) thread types available. Various options also available.
-
- Fluid: air and inert gas- Operating pressure: 0.1MPa to 1.0MPa
- Effective area (Cv): 1.7 to 3.6
- Coil rated voltage: 100, 200 VAC 50/60Hz; 24VDC
- Response time: 55 or less ms
- Ambient/fluid temp: -10 to +60 C
-
