Description
SY7000, 5 Port Solenoid Valve, All Types
Series SY offers major advances in valve performance for cost-effective solutions to your requirements. The series offers high flow with low power consumption in a compact design. The SY is available in body ported or base mounted styles and can be used individually or manifold mounted.
-
- Fluid: air- Operating pressure range: (internal pilot) 0.1 - 0.7MPa(external pilot) -100kPa to 0.7MPa(external pilot, pilot pressure range) 0.25 - 0.7MPa
- Effective area mm 2 (Cv): body ported 10.6 (0.59);base mounted 12.6 (0.7)
- Coil rated voltage: 3, 5, 6, 12, 24VDC;100, 110, 200, 220VAC
- Response time (0.5MPa) w/o indicator light surge voltage suppressor: 32ms or less
- Ambient fluid temperature: 50 C
Additional Information
Function: |
2 (2 Position Double) |
Piping: |
20 (Body Ported) |
Pilot: |
Internal Pilot |
Specifications: |
Standard |
Voltage: |
6 (12VDC) |
Lead Wire: |
LO (L Plug w/o Connector) |
Surge Suppressor: |
Z (Light & Surge Suppressor) |
Manual Override: |
Non-locking Push Style |
Port Size: |
02 (Body Ported 1/4, Base Mounted Sub-plate 1/4) |
Thread: |
T (NPTF) |
Option: |
None |
