SMC SYJ7240-5LOZ SY2000 Solenoid Valve, 2-Position Double Solenoid, 24 VDC
SMC
$79.20
SMC SYJ7240-5LOZ - Solenoid Valve Valve Model For CVRB1 Series
The SMC SYJ series is a compact pilot-operated solenoid valve for applications where mounting space is limited but full directional control is still required.
Specifications
| Valve Series | SYJ7000 Series C□VRB1BW80,100 |
| Type Of Actuation | 2-Position Double Solenoid |
| Rated Voltage | 24 VDC |
| Electrical Entry | L Plug Connector Without Connector |
| Light/Surge Voltage Suppressor | With Light/Surge Voltage Suppressor |
| Manual Override | Non-locking Push Type |
| Suffix | None |
Features
- Possible to move the auto switch mounting position as desired
- Direct mounting
- Connection port position: Side ported and axial ported selectable
- Low pressure operation: 0.15 MPa (Sizes 50 to 100)
- With auto switch (Series CDRB1: CDRB1, CDVRB1)
Applications
Used for compact cylinder control where panel space is limited.
Frequently Asked Questions
What voltage is the SMC SYJ7240-5LOZ?
The SYJ7240-5LOZ is rated 24 VDC.
What type of actuation does the SYJ7240-5LOZ use?
It is a 2-position double solenoid valve.
Automation Distribution is an authorized SMC distributor. Call 1-888-600-3080 for application support or volume pricing.
- Valve Series:
- SYJ7000 Series C□VRB1BW80,100
- Type Of Actuation:
- 2-Position Double Solenoid
- Rated Voltage:
- 24 VDC
- Electrical Entry:
- L Plug Connector Without Connector
- Light/Surge Voltage Suppressor:
- With Light/Surge Voltage Suppressor
- Manual Override:
- Non-locking Push Type
- Suffix:
- None
