Turck Bi2-Q5.5-An6X/S34/S1589 Inductive 1613044
Turck
$170.90
Manufacturer's Part Number: 1613044
Inductive Sensor. With Weldguard® coating. Ident. no.: 1613044. Rectangular, height 5.5 mm. Active face on top. Plastic, PP. DC 3-wire, 10
30 VDC. NO contact, NPN output. Cable connection
- Design:
- Rectangular
- Construction size:
- 28 x 8 x 5.5 mm, Q5.5
- Rated switching distance:
- 2 mm
- Mounting:
- Flush
- Operating voltage:
- 10?à30 VDC
- Output function:
- NO contact, NPN
- Switching frequency:
- 1.0 kHz
- Electrical connection:
- Cable
- Cable length (L):
- 2.0 m
- Housing material:
- Plastic, PP-GF20
- Ambient temperature:
- -25?à+70 ??C
- Protection class:
- IP67
- Special features:
- weldguard?«
- Catalog:
- View
- Datasheet:
- View
