Turck Bl20-2Ai-Thermo-Pi System-Io 6827020

TURCK Bl20-2Ai-Thermo-Pi System-Io 6827020

Turck
SKU:
BL20-2AI-THERMO-PI
Availability:
Factory stock: 1
$445.30
Condition:
New
Manufacturer's Part Number: 6827020
Current Stock:
Description
BL20 electronic module. 2 Analog Thermocouple Inputs. Ident. no.: 6827020. Fieldbus and connection technology independent. Protection class IP20. LEDs indicate status and diagnostic. Electronics galvanically separated from the field level via optocouplers. 2 analog inputs for connection of thermocouples, types B, E, J, K, N, R, S and T. Base module with internal cold compensation
Additional Information
Signal type:
Analog input, Temperature
Connection technology signal:
Screw terminal, Cage clamp terminal
Device type:
I/O Module
Ambient temperature:
0?à+55 ??C
Protection class:
IP20
Approvals:
cULus
Manual:
View
Catalog:
View
Datasheet:
View
