Turck Bl20-E-8Ai-U/I-4Pt/Ni System-Io 6827325
Turck
$551.20
Manufacturer's Part Number: 6827325
BL20 Economy Module. 8 2-wire Analog Inputs U/I resp. 4 2/3-wire PT/NI Inputs. Ident. no.: 6827325. Fieldbus-independent. Electronics and connection technology in one housing. Connectivity: Push-in terminals. Protection class IP20. LEDs indicate status and diagnostic. Electronics galvanically separated from the field level via optocouplers. 8 analog 2-wire inputs U/I. Passive input - External supply. 0
20 mA, 4
20 mA, -10
+10 VDC or 0
+10 VDC, selectable per channel . Alternatively: 4PT/NI inputs (always 2 analog inputs are combined to a PT/Ni 2/3-wire input)
