Turck Im31-12Ex-I Isolated Barriers 7506321
Turck
$484.20
Manufacturer's Part Number: 7506321
Analog signal isolator. 1-channel. Ident. no.: 7506321. Transmission of normalized analog signals from the Ex area to the non-Ex area. Input circuit: 0/2
10 V or 0/4
20 mA. Output circuit: 2 x 0/4 0
20 mA. Complete galvanic isolation. Input reverse-polarity protected. ATEX, IECEx, UL, CFMUS, TR CU, NEPSI, KOSHA. Installation in zone 2
- Signal type:
- Analog input
- Device type:
- Analog signal isolator - Input field side
- Ex version:
- yes
- Approvals:
- ATEX, IECEx, UL, cFMus, TR CU, NEPSI
- Nominal voltage:
- Wide voltage range
- Number of channels:
- 1
- Electrical connection:
- 4 ?ù 3-pin removable terminal blocks, reverse polarity protected, screw terminal
- Protection class:
- IP20
- Product series:
- IM
- Quick Start Guide:
- View
- Flyer:
- View
- Datasheet:
- View
