Turck

Turck Im34-12Ex-Ri Isolated Barriers 7506631

(No reviews yet) Write a Review
SKU:
IM34-12EX-RI
MPN:
7506631
Condition:
New
Signal type:
Temperature input
Device type:
Temperature measuring amplifier
Ex version:
yes
Approvals:
ATEX, IECEx, UL, cFMus, TR CU, INMETRO, CCOE
Nominal voltage:
Wide voltage range
Number of channels:
1
Digital output:
Relay output
Electrical connection:
4 ?ù 3-pin removable terminal blocks, reverse polarity protected, screw terminal
Protection class:
IP20
Product series:
IM
Quick Start Guide:
View
Flyer:
View
Datasheet:
View
  • Turck Im34-12Ex-Ri Isolated Barriers 7506631
  • Turck Im34-12Ex-Ri Temperature measuring amplifier, 1-channel, TšV 02 ATEX 1898
$819.10

Description

Temperature measuring amplifier. 1-channel. Ident. no.: 7506631. Input for Pt100/ Ni100 resistors, thermocouples and millivolt signals in 2, 3 or 4-wire technology. Output circuit: 0/4…20 mA, limit value relay. Upper and lower limit adjustable via rotary coding switch. Complete galvanic isolation. Input reverse-polarity protected. ATEX, IECEx, CFMUS, UL, TR CU, INMETRO, CCOE, NEPSI, KOSHA. Installation in zone 2
