Turck Ni15U-Em18Wdtc-Ap6X Inductive 1634763
Turck
$209.80
Manufacturer's Part Number: 1634763
Inductive Sensor. For the Food Industry. Ident. no.: 1634763. Threaded barrel, M18 x 1. Stainless steel, 1.4404. Front cap made of liquid crystal polymer. Factor 1 for all metals. Resistant to magnetic fields. For temperatures of -40 °C
+100 °C. High protection class IP69K for harsh environments. Special double-lip seal. Protection against all common acidic and alkaline cleaning agents. Suitable for applications in the food industry. DC 3-wire, 10
30 VDC. NO contact, PNP output. Terminal chamber
- Design:
- Threaded barrel
- Construction size:
- M18 x 1
- Rated switching distance:
- 15 mm
- Mounting:
- Non-flush
- Operating voltage:
- 10?à30 VDC
- Output function:
- NO contact, PNP
- Switching frequency:
- 1.0 kHz
- Electrical connection:
- Terminal chamber, Removable cage clamp terminals
- Housing material:
- Stainless steel, 1.4404 (AISI 316L)
- Ambient temperature:
- -40?à+100 ??C
- Protection class:
- IP68/IP69K
- Special features:
- uprox+, Wash down, Factor 1, Sn +, Resistant to magnetic fields, Pressure resistant
- Quick Start Guide:
- View
- Catalog:
- View
- Datasheet:
- View
