Turck Ri-10S8C-4B4096-H1181 Encoder 100022303
Turck
$390.00
Manufacturer's Part Number: 100022303
Incremental Shaft Encoder. Industrial Line. Ident. no.: 100022303. Clamping flange, à 58 mm. Solid shaft, à 8 mm à 15 mm. Optical measuring principle. Shaft material: stainless steel. Protection class IP67 on housing and shaft side. 40
+85 °C. Max. 6000 rpm (continuous operation 3000 rpm). 5
30 VDC. Male connector, M12 x 1 , 8-pole. RS422 with inverted signals. Pulse frequency max. 300 kHz. 4096 pulses per revolution
- Encoder line:
- Industrial-Line
- Technology:
- Optical
- Output type:
- Incremental
- Shaft Type:
- Solid shaft
- Shaft diameter D (mm):
- 8
- Flange diameter:
- Ø 58 mm
- Flange type:
- Clamping flange
- Resolution incremental:
- 4096 ppr
- Operating voltage:
- 5 30 VDC
- Output function:
- RS422/TTL, with inverted signals
- Electrical connection:
- Connector, M12 × 1
- Housing material:
- Die-cast zinc
- Ambient temperature:
- -40 +85 °C
- Protection class shaft:
- IP67
- Protection class:
- IP67
