Description
series vr1210/1200 shuttle valve is a 3 ported valve with one output and 2 pneumatic signal and input ports. output is always supplied by high pressure inlet. the vr12**f series are interrupters for control of air pressure signal system lines. piping is possible in any position and the one-touch fittings make piping connections simple. time delay valve series vr2110 with its combination of adjustable orifice and fixed flow allows transmission of a pneumatic signal after a fixed time period.
- supply pressure: 0 to 1.0 mpa
- signal pressure: 0.25 to 0.8mpa
- time delay: 0.5 to 60s
- operating and fluid temp: -5 to 60c (no freezing)
- effective area (cv): 0.14
