WAGO 2010-7111
- SKU:
- 2010-7111
- Condition:
- New
- actuation type:
- Push-in || Operating tool
- color:
- Gray
- connectable conductor materials:
- Copper
- connection technology:
- Push-in CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 38.1 mm / 1.5 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.5 16 mm / 20 6 AWG
- fine stranded conductor with ferrule push in termination:
- 4 10 mm / 12 8 AWG
- fine stranded conductor with insulated ferrule:
- 0.5 10 mm / 20 8 AWG
- fire load:
- 0.323 MJ
- flammability class per ul94:
- V0
- height:
- 67.3 mm / 2.65 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Center/side marking
- mounting type:
- DIN-35 rail
- nominal cross section:
- 10 mm
- nominal voltage iii 3:
- 250 V
- note conductor cross section:
- Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
- packaging type:
- Box
- rated current:
- 57 A
- rated surge voltage iii 3:
- 4 kV
- solid conductor:
- 0.5 16 mm / 20 6 AWG
- solid conductor push in termination:
- 4 16 mm / 14 6 AWG
- strip length:
- 17 19 mm / 0.67 0.75 inch
- weight:
- 21.722 g
- width:
- 10 mm / 0.394 inch
- wiring direction:
- Front-entry wiring
Description
1-conductor power distribution disconnect terminal block; 10 mm; Push-in CAGE CLAMP; 10,00 mm; gray
View AllClose
Electrical Data
- Rated voltage (III / 3): 250 V
- Rated impulse voltage (III / 3): 4 kV
- Rated current: 57 A
- Legend (ratings): (III / 3) Overvoltage category III / Pollution degree 3
Connection Data
- Connection technology: Push-in CAGE CLAMP<sup></sup>
- Actuation type: Operating tool
- Connectable conductor materials: Copper
- Nominal cross section: 10 mm
- Solid conductor: 0.5 16 mm / 20 6 AWG
- Solid conductor, push-in termination: 4 16 mm / 14 6 AWG
- Fine-stranded conductor: 0.5 16 mm / 20 6 AWG
- Fine-stranded conductor with ferrule with plastic collar: 4 10 mm / 12 8 AWG
- Fine-stranded conductor with ferrule, push-in termination, from: 4 10 mm / 12 8 AWG
- Strip length: 17 19 mm / 0.67 0.75 inch
- Total number of connection points: 1
- Total number of potentials: 1
- Number of levels: 1
- Type of wiring: Front-entry wiring
- Note (conductor cross-section): Depending on the conductor characteristic, a conductor with a smaller cross section can also be inserted via push-in termination.
- Number of jumper slots: 2
Geometrical Data
- Width: 10 mm / 0.394 inch
- Height from upper-edge of DIN-35 rail: 38.1 mm / 1.5 inch
- Depth: 67.3 mm / 2.65 inch
Mechanical Data
- Design: horizontal
- Type of mounting: DIN-35 rail
- Marking level: Center/side marking
Material Data
- Color: gray
- Insulating material: Polyamide 66 (PA 66)
- Fire load: 0.000 MJ
- Weight: 21.763 g
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4055143879774
- Customs Tariff No.: 85365080900
