Wago 2091-1162

WAGO 2091-1162 1-conductor THT female header; 1.0 mm Ø solder pin; straight; Gripping plate; 1.5 mm²; Pin spacing 3.5 mm; 12-pole; 1,50 mm²; light gray

Wago
SKU:
20911162
$9.15
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
1-conductor THT female header; 1.0 mm solder pin; straight; Gripping plate; direct marking; 1.5 mm; Pin spacing 3.5 mm; 12-pole.

The WAGO component equivalent to 20911162 is a specific part or model within the WAGO product line, which is known for its high-quality electrical interconnection and automation solutions. This component is likely used in various industrial and commercial applications, providing reliable performance and compatibility with other WAGO products. It is designed to meet specific technical requirements and standards, ensuring efficient and safe operation in its intended use cases.

Additional Information
actuation type:
Push-button
approvals per:
UL 1059
clamping spring material:
Chrome nickel spring steel (CrNi)
color:
Light gray
conductor connection direction to pcb:
90
connection technology:
Push-in CAGE CLAMP
connector connection type:
For PCB
contact material:
Electrolytic copper (ECu)
contact plating:
Tin-plated
contact type pluggable connector:
Female connector/socket
country of origin sales organisation germany:
DE
depth:
11.4 mm / 0.449 inch
design:
With gripping plate
drilled hole diameter with tolerance:
1.2 (+0.1) mm
fine stranded conductor:
0.2 1.5 mm / 24 14 AWG
fine stranded conductor with insulated ferrule:
0.25 0.75 mm
fine stranded conductor with uninsulated ferrule:
0.25 1.5 mm
fire load:
0.033 MJ
flammability class per ul94:
V0
height:
38 mm / 1.496 inch
insulation material:
Polyphthalamide (PPA GF)
legend ratings:
(III / 2) Overvoltage category III / Pollution degree 2
limit temperature range:
-60 +100 C
locking of plug in connection:
Without
material group:
I
mating direction to the pcb:
90
mismating protection:
No
nominal voltage ii 2:
320 V
nominal voltage iii 3:
160 V
packaging type:
Box
pcb contact:
THT
pin spacing:
3.5 mm / 0.138 inch
pole no:
12
rated current:
0.416666666666667
rated current ul use group b:
0.416666666666667
rated current ul use group d:
0.416666666666667
rated surge voltage ii 2:
2.5 kV
rated surge voltage iii 2:
2.5 kV
rated surge voltage iii 3:
2.5 kV
rated voltage iii 2:
160 V
rated voltage ul use group b:
300 V
rated voltage ul use group d:
300 V
ratings per:
IEC/EN 60664-1
safety information 1:
The picoMAX Pluggable Connection System includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should en
solder pin diameter:
1 mm
solder pin length:
3.6 mm
solid conductor:
0.2 1.5 mm / 24 14 AWG
strip length:
8 9 mm / 0.31 0.35 inch
weight:
7.230 g
width:
42 mm / 1.654 inch
