Wago 221-613/K194-4045 LEVER-NUTS 3-Conductor Splicing Connector, 20-10 AWG, Transparent, Box of 30

## Product Description The WAGO 221-613 COMPACT splicing connector is a three-conductor wire termination device utilizing CAGE CLAMP® push-in technology with manual lever actuation. Rated for 450 V nominal (600 V UL) and 41 A continuous current, it accommodates solid, stranded, and fine-stranded copper conductors from 0.5 to 6 mm² (20–10 AWG) with a simple pull-lever, insert-conductor, push-lever operation. The transparent polycarbonate housing provides visual confirmation of proper wire insertion and strip length, while dual test points (front and back) enable in-situ continuity testing without disconnection. Side-entry wiring design supports mounting on DIN-rail carriers or direct panel installation; open-face construction allows access for wiring and testing even after carrier installation. Operating temperature range is 85 °C ambient (T85 designation) with 105 °C continuous rating. The connector conforms to UL 486C, IEC/EN 60664-1, and EN 60998 standards and achieves V2 flammability classification per UL94, making it suitable for industrial control, lighting, and power distribution applications requiring secure, tool-free terminations. Documentation - Technical Datasheet: https://www.wago.com/us/wire-splicing-connectors/compact-splicing-connector/p/221-613 - Installation and Handling Guide: https://www.wago.com/us/products/wire-splicing-connectors/221-series/installation-guide - 221 Series Product Family Overview: https://www.wago.com/us/products/wire-splicing-connectors/221-series-lever-nuts - Mounting Carrier Compatibility and Accessories: https://www.wago.com/us/products/wire-splicing-connectors/221-series/mounting-carriers
