Male connectorwith strain relief, white
- Flexible connection system with PUSH WIRE<sup></sup> connection
- Phase selection
The WAGO component equivalent to 277127 is a specific part used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, ensuring secure and maintenance-free connections. This component is typically used in various applications, including industrial automation, building technology, and process control, offering high performance and durability.
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- White
- connection technology:
- PUSH WIRE
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- DE
- depth:
- 40 mm / 1.575 inch
- fire load:
- 0.243 MJ
- flammability class per ul94:
- V0
- height:
- 30.8 mm / 1.213 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- material group:
- I
- packaging type:
- Bag
- pole no:
- 4
- rated current:
- 0.416666666666667
- rated surge voltage iii 2:
- 4 kV
- rated voltage iii 2:
- 400 V
- ratings per:
- IEC/EN 60664-1
- strip length:
- 10 11 mm / 0.39 0.43 inch
- temperature stability:
- 105 C
- weight:
- 14.530 g
- width:
- 45 mm / 1.772 inch
