Wago 281-101

WAGO 281-101 2-conductor through terminal block; 4 mm²; lateral marker slots; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 4,00 mm²; gray

Wago
SKU:
51043959
$2.41
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
2-conductor through terminal block; 4 mm²; lateral marker slots; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 4,00 mm²; gray.

The WAGO 281 series feed-through terminal block is a gray, single-deck unit with side marking slots, designed for one feed-through pole and two wires using one clamp each. It accommodates wire sizes from 0.08mm² to 4mm² (#28AWG to #12AWG) and supports a rated current of 32A. The terminal block features CAGE CLAMP spring connections and mounts on a DIN-35 rail (35 x 15 / 35 x 7.5) with a width of 6mm, equivalent to model 281101.

Additional Information
actuation type:
Operating tool
connectable conductor materials note:
Terminating Aluminum ConductorsWAGO spring clamp terminal blocks are suitable for solid aluminum conductors up to 4 mm/12 AWG if WAGO Alu-Plus Contact Paste is used for termination.Alu-Plus Contact Paste Advantages:Automatically
color:
Gray
connectable conductor materials:
Copper || Aluminum
connection technology:
CAGE CLAMP
country of origin sales organisation germany:
IN
depth from upper edge of din rail:
32.5 mm / 1.28 inch
design:
Horizontal type
fine stranded conductor:
0.08 4 mm / 28 12 AWG
fire load:
0.108 MJ
flammability class per ul94:
V0
height:
42.5 mm / 1.673 inch
insulation material:
Polyamide (PA66)
legend ratings:
(III / 3) Overvoltage category III / Pollution degree 3
marking level:
Side marking
mounting type:
DIN-35 rail
nominal voltage iii 3:
800 V
packaging type:
Box
rated current:
32 A
rated surge voltage iii 3:
8 kV
ratings per:
IEC/EN 60947-7-1
solid conductor:
0.08 4 mm / 28 12 AWG
strip length:
9 10 mm / 0.35 0.39 inch
weight:
5.887 g
width:
6 mm / 0.236 inch
wiring direction:
Side-entry wiring
