Wago

Wago 706-2300/601-300 S-Cable, S7-300 A6ESI

SKU:

706-2300/601-300

UPC:

MPN:

706-2300/601-300

Condition:

New

cable length:

3 m

cable type:

LiYCY

color code:

Per DIN VDE 47100

compatible plc i o card types:

6ES7 334-0CE01-0AA0

compatible plc modules:

Siemens S7-300

connection type 1:

System

connection type 2:

System

connector 2:

Siemens 6ES7-392-1BJ00-0AA0

current per wire max:

0.0833333333333333

fire load:

0.000 MJ

inputs outputs:

6 analog inputs or outputs: current

note:

When using more than 10 wires, the maximum current per wire must be reduced to 1 A.

operating voltage:

ëñ AC/DC 35 V

packaging type:

Box

pluggable connectors:

D-sub female connector

pole number 1:

25

pole number 2:

20

surrounding air temperature operation:

-20 Ǫ 50 C

weight:

1.111 g

wire cross section:

0.25 mm
