WAGO 713-1110/107-000 20-Pole Female Connector, 1.5 mm², CAGE CLAMP®, 10A
Wago
$23.46
1-conductor female connector, 2-row; CAGE CLAMP; 1.5 mm²; Pin spacing 3.5 mm; 20-pole; 100% protected against mismating; Screw flange; 1,50 mm²; black.
The WAGO component equivalent to 7131110107000 is a specific type of electrical connector or terminal block used for secure and reliable electrical connections. It is designed to meet industry standards and provide efficient performance in various electrical applications. This component ensures safe and stable connections, making it suitable for use in a wide range of electrical systems and installations.
- actuation type:
- Operating tool
- approvals per:
- UL 1059
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- Color:
- Black
- conductor entry direction to mating direction:
- 0
- connection technology:
- CAGE CLAMP
- connector connection type:
- For conductor
- contact material:
- Copper alloy
- contact plating:
- Tin-plated
- contact type pluggable connector:
- Female connector/socket
- country of origin sales organisation germany:
- PL
- depth:
- 16 mm / 0.63 inch
- fine stranded conductor:
- 0.08 1.5 mm / 28 16 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 1 mm
- fine stranded conductor with uninsulated ferrule:
- 0.25 1 mm
- fire load:
- 0.157 MJ
- flammability class per ul94:
- V0
- height:
- 18.8 mm / 0.74 inch
- insulation material:
- Glass fiber-reinforced polyamide (PA66 GF)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +100 C
- locking of plug in connection:
- Screw flange
- material group:
- II
- mismating protection:
- Yes
- nominal voltage ii 2:
- 250 V
- nominal voltage iii 3:
- 80 V
- packaging type:
- Box
- pin spacing:
- 3.5 mm / 0.138 inch
- pole no:
- 20
- rated current:
- 0.416666666666667
- rated current csa use group b:
- 0.416666666666667
- rated current ul use group b:
- 0.416666666666667
- rated current ul use group c:
- 0.416666666666667
- rated surge voltage ii 2:
- 2.5 kV
- rated surge voltage iii 2:
- 2.5 kV
- rated surge voltage iii 3:
- 2.5 kV
- rated voltage csa use group b:
- 300 V
- rated voltage iii 2:
- 160 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group c:
- 50 V
- ratings per:
- IEC/EN 60664-1
- safety information 1:
- The MCS MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure
- solid conductor:
- 0.08 1.5 mm / 28 16 AWG
- strip length:
- 6 7 mm / 0.24 0.28 inch
- weight:
- 10.890 g
- width:
- 45.1 mm / 1.776 inch
