Wago 721-172/003-000

WAGO 721-172/003-000 Male connector for rail-mount terminal blocks; 1.2 x 1.2 mm pins; straight; 100% protected against mismating; Pin spacing 5 mm; 12-pole; light gray

Wago
SKU:
51151079
$7.07
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
Description Male connector; with straight, long contact pins; 12-pole; Pin spacing 5 mm / 0.197 mm; 100% protected against mismating; 1.2x1.2 mm; with closed end; Vertical mounting; codable
Remarks Item description:
  • Pluggable connectors for rail-mounted terminal blocks equipped with CAGE CLAMP
  • Male connectors with long contact pins connect to the termination ports of 280 Series rail-mounted terminal blocks
  • Pins can be touched when the connector is unplugged, so power supply should be performed via terminal block (observe rated voltage!)
  • 100% protected against mismating
  • Coding option available



Item properties

Miscellaneous

Name Value Unit
No. of poles  12
Pin spacing  5 mm (0.197 in)
Color  light gray
Ratings per  IEC/EN 60664-1
Rated voltage (III / 3) [V]  250  V
Rated impulse voltage (III / 3) [kV]  4  kV
Rated voltage (III/2) [V]  630  V
Rated impulse voltage (III / 2) [kV]  4  kV
Rated voltage (II / 2) [V]  320  V
Rated impulse voltage (II / 2) [kV]  4  kV
Rated current [A]  16  A
Legend for ratings  (III / 2) Overvoltage category III / Pollution degree 2
Number of levels  1
Material group  I
Insulating material  Polyamide 66 (PA 66)
Flammability class per UL94  V0
Limit temperature range  -60 100
Contact material  Electrolytic copper (Ecu)
Contact plating  tin-plated
Fire load [MJ]  0.095  MJ
Weight [g]  6.88  g
Width  63.2 mm / 2.488 Inch
Height  25.9 mm / 1.02 Inch
Height from the surface  12 mm / 0.472 Inch
Depth  11.4 mm / 0.449 Inch
Pin spacing from [mm]  5  mm
.

The WAGO component equivalent to 721172003000 is a specific part used in electrical and electronic applications, known for its reliability and efficiency. This component is typically utilized in various industrial and automation systems, providing secure and maintenance-free connections. It is designed to meet high standards of performance and safety, ensuring optimal functionality in demanding environments. The equivalent part offers similar specifications and compatibility, making it a suitable replacement for the original WAGO component.

Additional Information
approvals per:
CSA
color:
Light gray
connector connection type:
For front-entry rail-mount terminal block
contact material:
Electrolytic copper (ECu)
contact plating:
Tin-plated
contact type pluggable connector:
Male connector/plug
country of origin sales organisation germany:
PL
depth:
11.4 mm / 0.449 inch
fire load:
0.095 MJ
flammability class per ul94:
V0
height:
25.9 mm / 1.02 inch
height from the surface:
12 mm / 0.472 inch
insulation material:
Polyamide (PA66)
legend ratings:
(III / 2) Overvoltage category III / Pollution degree 2
limit temperature range:
-60 +85 C
locking of plug in connection:
Without
material group:
I
mismating protection:
Yes
nominal voltage ii 2:
630 V
nominal voltage iii 3:
250 V
packaging type:
Box
pin spacing:
5 mm / 0.197 inch
pole no:
12
rated current:
16 A
rated current csa use group b:
15 A
rated current csa use group d:
0.416666666666667
rated current ul 1977:
15 A
rated current ul use group b:
15 A
rated current ul use group d:
0.416666666666667
rated surge voltage ii 2:
4 kV
rated surge voltage iii 2:
4 kV
rated surge voltage iii 3:
4 kV
rated voltage csa use group b:
300 V
rated voltage csa use group d:
300 V
rated voltage iii 2:
320 V
rated voltage ul 1977:
600 V
rated voltage ul use group b:
300 V
rated voltage ul use group d:
300 V
ratings per:
IEC/EN 60664-1
safety information 1:
The MCS MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure
weight:
6.968 g
width:
63.2 mm / 2.488 inch
