WAGO 726-821 Matrix Patchboard, 80-Pole, Marked 1-80, Front-Entry Wiring, CAGE CLAMP® Technology
Wago
$351.50
Matrix patchboard; 80-pole; Marking 1-80; Colors of modules: gray/white; Module marking, side 1 and 2 vertical; 1,50 mm²; dark gray.
The WAGO 726 series marked matrix patchboard is a gray and white module with a "1-80" marking, featuring 80 feed-through poles arranged in 10 columns and 8 points, accommodating 2 or 3 wires each, totaling 240 wires (clamps). It supports wire sizes from 0.08mm² to 1.5mm² (#28AWG to #16AWG) and is rated for a current of 10A. The patchboard utilizes CAGE CLAMP spring connections for secure and reliable surface mounting, equivalent to model 726821.
- actuation type:
- Operating tool
- Color:
- Dark Gray
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- connection type 1:
- Page 1
- connection type 2:
- Page 2
- country of origin sales organisation germany:
- DE
- depth:
- 36.5 mm / 1.437 inch
- fine stranded conductor:
- 0.08 1.5 mm / 28 16 AWG
- fine stranded conductor 2:
- 0.08 2.5 mm / 28 14 AWG
- fire load:
- 4.840 MJ
- height:
- 132 mm / 5.197 inch
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking:
- 1 80
- module color:
- White/gray
- nominal voltage iii 3:
- 500 V
- number of connection points:
- 3
- number of connection points 2:
- 2
- packaging type:
- Box
- pole no:
- 80
- rated current:
- 0.416666666666667
- rated surge voltage iii 3:
- 6 kV
- solid conductor:
- 0.08 1.5 mm / 28 16 AWG
- solid conductor 2:
- 0.08 2.5 mm / 28 14 AWG
- strip length:
- 8 10 mm / 0.31 0.39 inch
- weight:
- 439.200 g
- width:
- 107.9 mm / 4.248 inch
- wiring direction:
- Front-entry wiring
