8-level same potential terminal block; with locking clips; all clamping units internally commoned; with 2.3 mm à test port; marking: a-b-c-d-e-f-g-h--h-g-f-e-d-c-b-a; for 35 x 7.5 mounting rail; 1.5 mm²; 1,50 mm²; light gray.
The WAGO 727 series is a light gray feed-through common potential terminal block featuring 8 decks/levels, cover locking clips, and a center marking slot with "a-b-c-d-e-f-g-h--h-g-f-e-d-c-b-a" markings. It has one feed-through pole (1P) and accommodates 32 wires (16 clamps on each side), suitable for wire sizes ranging from 0.08mm² to 1.5mm² or #28AWG to #16AWG. The terminal block supports a rated current of 18A and utilizes CAGE CLAMP spring connections. It is designed for mounting on a DIN-35 rail (35 x 7.5) with a width of 7.62mm, equivalent to model 727127002000.
- actuation type:
- Operating tool
- color:
- Light gray
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 76 mm / 2.992 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 1.5 mm / 28 16 AWG
- fire load:
- 1.187 MJ
- flammability class per ul94:
- V0
- height:
- 226 mm / 8.898 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking:
- A-b-c-d-e-f-g-h--h-g-f-e-d-c-b-a
- marking level:
- Center marking
- mounting type:
- DIN-35 rail
- nominal voltage iii 3:
- 250 V
- packaging type:
- Box
- rated current:
- 18 A
- rated surge voltage iii 3:
- 4 kV
- solid conductor:
- 0.08 1.5 mm / 28 16 AWG
- strip length:
- 8 10 mm / 0.31 0.39 inch
- weight:
- 62.000 g
- width:
- 7.62 mm / 0.3 inch
- wiring direction:
- Front-entry wiring
