WAGO 731-163 Feedthrough Terminal Block; 3-Pole; 1.5 mm Plate Thickness; 2.5 mm²; 5.08 mm Pin Spacing; CAGE CLAMP; Orange
Wago
$7.88
Through-panel PCB terminal strip; wire-wrap pin 1 x 1 mm; 3-pole; pin spacing 5.08 mm / 0.2 in; for flush-mounting; orange.
The WAGO component equivalent to 731163 is a specific type of electrical connector or terminal block used for various wiring applications. It is designed to provide secure and reliable connections in electrical circuits, ensuring efficient conductivity and safety. This component is commonly used in industrial, commercial, and residential electrical installations, offering ease of use and durability. The equivalent model to 731163 maintains the same high standards of performance and compatibility with existing systems, making it a suitable replacement or alternative for users needing a reliable connection solution.
- actuation type:
- Operating tool
- approvals per:
- UL 1059
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Orange
- connection technology:
- CAGE CLAMP
- connection technology 2:
- Wire-wrap pin
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- DE
- depth:
- 15.5 mm / 0.61 inch
- fine stranded conductor:
- 0.08 2.5 mm / 28 14 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 1.5 mm
- fine stranded conductor with uninsulated ferrule:
- 0.25 2.5 mm
- fire load:
- 0.091 MJ
- flammability class per ul94:
- V0
- height:
- 14.3 mm / 0.563 inch
- housing sheet thickness:
- 1.5 1.5 mm / 0.059 0.059 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- mounting type:
- Mounting flange || Feed-through mounting || Panel mounting
- nominal voltage ii 2:
- 630 V
- nominal voltage iii 3:
- 320 V
- packaging type:
- Box
- pin spacing:
- 5.08 mm / 0.2 inch
- pole no:
- 3
- rated current:
- 0.208333333333333
- rated current csa use group b:
- 0.208333333333333
- rated current ul use group b:
- 0.208333333333333
- rated current ul use group c:
- 0.208333333333333
- rated current ul use group d:
- 0.208333333333333
- rated surge voltage ii 2:
- 4 kV
- rated surge voltage iii 2:
- 4 kV
- rated surge voltage iii 3:
- 4 kV
- rated voltage csa use group b:
- 300 V
- rated voltage iii 2:
- 320 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group c:
- 150 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solid conductor:
- 0.08 2.5 mm / 28 14 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 5.159 g
- width:
- 30.44 mm / 1.198 inch
