WAGO 750-332

BACnet/IP FC G4, 1 pcs.

Technical Data

• Communication: Modbus (TCP, UDP)
• Ethernet protocol: SNMP
• Device-specific: BACnet device profile: B-BC (BACnet Building Controller); BACnet version: 12
• Baud rate: 10/100 Mbit/s
• Transmission medium: Twisted Pair S-UTP; 100 Cat. 5; Line length (max.): 100 m
• Transmission performance: Class D acc. to EN 50173
• Type of memory card: SD and SDHC up to 32 GB (All guaranteed properties are only valid in connection with the WAGO 758-879/000-001 memory card.)
• Memory card slot: Push-push mechanism, sealable cover lid
• Number of modules per node max.: 250
• Number of I/O modules without bus extension max.: 64
• Configuration options: Web-based management
• Input and output process image (Fieldbus) max.: 1020 Worte/1020 Worte
• System supply voltage: DC 24 V(-25 ˜ +30 %); via wiring level (CAGE CLAMP connection)
• Current consumption, system supply (5 V): 440 mA
• Total current for system supply: 1700 mA
• Field supply voltage: DC 24 V (-25 ˜ +30 %); via power jumper contacts
• Input current typ. at rated load (24 V): 500 mA
• Efficiency of the power supply (typ.) at nominal load (24 V): 90 %
• Isolation: 500 V system/supply
• Number of outgoing power jumper contacts: 3
• Current carrying capacity of the power jumper contacts: 10 A

Connection Data

• Connection technology: communication/fieldbus: BACnet/IP: 2 x RJ-45; Modbus TCP/UDP: 2 x RJ-45
• Connection technology: field supply: 6 x CAGE CLAMP
• Connection technology: system supply: 2 x CAGE CLAMP
• Connection technology: Device configuration: 1 x 4-pole male connector
• Connection type (1): System/field supply
• Solid conductor: 0.08 ˜ 2.5 mm / 28 ˜ 14 AWG
• Fine-stranded conductor: 0.08 ˜ 2.5 mm / 28 ˜ 14 AWG
• Strip length: 8 ˜ 9 mm / 0.31 ˜ 0.35 inch

Geometrical Data

• Width: 61.5 mm / 2.421 inch
• Height: 71.9 mm / 2.831 inch
• Height from upper-edge of DIN-35 rail: 64.7 mm / 2.547 inch
• Depth: 100 mm / 3.937 inch

Mechanical Data

• Type of mounting: DIN-35 rail

Material Data

• Housing material: Polycarbonate, polyamide 6.6
• Fire load: 0.000 MJ
• Weight: 155.927 g

Environmental Requirements

• Surrounding air (operating) temperature: 0 ˜ 55 C
• Surrounding air (storage) temperature: -40 ˜ 85 C
• Protection class: IP20
• Degree of pollution (5): 2 per IEC 61131-2
• Operating altitude: 0 ˜ 2000 m
• Mounting position: horizontal (standing/lying) or vertical
• Relative air humidity (no condensation): 95 %
• Vibration resistance: acc. to IEC 60068-2-6
• Shock resistance: 15g per IEC 60068-2-27
• EMC immunity to interference: acc. to EN 61000-6-2
• EMC emission of interference: acc. to EN 61000-6-3
• Exposure to pollutants: Per IEC 60068-2-42 and IEC 60068-2-43
• Permissible H₂S contaminant concentration at a relative humidity <lt/> 75 %: 10 ppm
• Permissible SO₂ contaminant concentration at a relative humidity <lt/> 75 %: 25 ppm

Commercial data

• Packaging type: BOX
• Country of origin: DE
• GTIN: 4055143888721
• Customs Tariff No.: 85371091990

.

The WAGO 750 series Fieldbus coupler/head (remote I/O controller unit) supports up to 250 connections per node and 64 field devices, featuring Modbus TCP and BACnet/IP communication capabilities. It operates on a 24Vdc supply via system wiring and power jumper, includes two RJ45 connectors for fieldbus, spring CAGE CLAMP for power supply connections, and a 4-pin male connector for device configuration. Designed for DIN-35 rail mounting with a width of 61.5mm, it also has an SD and SDHC card slot supporting up to 32GB. The unit is rated IP20 and suitable for ambient temperatures from 0°C to +55°C, equivalent to model 750332.
