Description
FC Modbus TCPG4
View AllClose
Technical Data
- Communication: Modbus (TCP, UDP)
- Ethernet protocol: SNMP
- Baud rate: 10/100 Mbit/s
- Transmission medium: Twisted Pair S-UTP; 100 Cat. 5; Line length (max.): 100 m
- Transmission performance: Class D acc. to EN 50173
- Number of modules per node max.: 250
- Number of I/O modules without bus extension max.: 64
- Input and output process image (Fieldbus) max.: 1020 Worte/1020 Worte
- System supply voltage: DC 24 V(-25 +30 %); via wiring level
- Current consumption, system supply (5 V): 350 mA
- Total current for system supply: 700 mA
- Input current typ. at rated load (24 V): 280 mA
- Efficiency of the power supply (typ.) at nominal load (24 V): 90 %
- Isolation: 500 V system/supply
- Indicators: LED (LINK/ACT) green: Network connection Port 1 2; LED (MS, NS) red/green: Status of node, network; LED (I/O) red/green/orange: Internal data bus status
Connection Data
- Connection technology: communication/fieldbus: Modbus TCP/UDP: 2 x RJ-45
- Connection technology: system supply: 2 x CAGE CLAMP<sup></sup>
- Connection technology: Device configuration: 1 x 4-pole male connector
- Connection type (1): System supply
- Solid conductor: 0.08 2.5 mm / 28 14 AWG
- Fine-stranded conductor: 0.08 2.5 mm / 28 14 AWG
- Strip length: 8 9 mm / 0.31 0.35 inch
Geometrical Data
- Width: 49.5 mm / 1.949 inch
- Height: 71.9 mm / 2.831 inch
- Height from upper-edge of DIN-35 rail: 64.7 mm / 2.547 inch
- Depth: 96.8 mm / 3.811 inch
Mechanical Data
- Type of mounting: DIN-35 rail
Material Data
- Housing material: Polycarbonate, polyamide 6.6
- Fire load: 0.000 MJ
- Weight: 104.800 g
- Conformity marking: CE
Environmental Requirements
- Surrounding air (operating) temperature: 0 55 C
- Surrounding air (storage) temperature: -40 85 C
- Protection class: IP20
- Degree of pollution (5): 2 per IEC 61131-2
- Operating altitude: 0 2000 m
- Mounting position: horizontal (standing/lying) or vertical
- Relative air humidity (no condensation): 95 %
- Vibration resistance: 4g per IEC 60068-2-6
- Shock resistance: 15g per IEC 60068-2-27
- EMC immunity to interference: acc. to EN 61000-6-2, marine applications
- EMC emission of interference: acc. to EN 61000-6-3, marine applications
- Exposure to pollutants: Per IEC 60068-2-42 and IEC 60068-2-43
- Permissible H<sub>2</sub>S contaminant concentration at a relative humidity <lt/> 75 %: 10 ppm
- Permissible SO<sub>2</sub> contaminant concentration at a relative humidity <lt/> 75 %: 25 ppm
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4055143821421
- Customs Tariff No.: 85176200000
The WAGO 750 series Gen.4 Fieldbus coupler/head (remote I/O controller unit) with Modbus TCP communication capability supports up to 250 connections per node and 64 field devices. It operates on a 24Vdc supply voltage via system wiring and features 2 RJ45 connectors for fieldbus, spring CAGE CLAMP for power supply connections, and a 4-pin male connector for device configuration. Designed for DIN-35 rail mounting with a width of 49.5mm, it is rated for ambient temperatures from 0°C to +55°C and has an IP20 protection rating, equivalent to model 750362.
