Wago

WAGO 750-429/040-001

SKU:

750-429/040-001

UPC:

MPN:

750-429/040-001

Condition:

New

color:

Dark gray

conformity marking:

CE

connection technology inputs outputs:

8 x CAGE CLAMP

connection type 1:

Inputs/outputs

country of origin sales organisation germany:

DE

current carrying capacity power jumper contacts:

0.416666666666667

depth:

67.8 mm / 2.669 inch

depth from upper edge of din rail:

60.6 mm / 2.386 inch

dielectric strength:

2.5 kV (AC)/3.5 kV (DC): per EN 60870-2-1

emc emission of interference:

Per EN 61000-6-3, -4, EN 61131-2, EN 60255-26, marine applications, EN 60870-2-1, EN 61850-3, EN 50121-3-2, EN 50121-4, -5

emc immunity to interference:

Per EN 61000-6-1, -2: EN 61131-2: marine applications: EN 50121-3-2: EN 50121-4, -5: EN 60255-26: EN 60870-2-1: EN 61850-3: IEC 61000-6-5: IEEE 1613: VDEW: 1994

exposure to pollutants:

Per IEC 60068-2-42 and IEC 60068-2-43

fine stranded conductor:

0.25 2.5 mm / 24 14 AWG

fire load:

0.147 MJ

height:

100 mm / 3.937 inch

housing material:

Polycarbonate: polyamide 6.6

indicators:

LED (A, E) green: Status DI 1, DI 2

input characteristic:

High-side/low-side switching, configurable

input current per channel for signal 1 typ:

2.9 mA

input data width internal max:

2 bits

input filter digital:

3 ms

mounting position:

Horizontal (standing/lying): vertical

mounting type:

DIN-35 rail

number of digital inputs:

2

number of incoming power jumper contacts:

2

number of outgoing power jumper contacts:

2

operating altitude:

Without temperature derating: 0 2000 m: with temperature derating: 2000 5000 m (0.5 K/100 m): 5000 m (max.)

overvoltage category:

Nominal voltage 110 V: III (EN 61010-1 / up to 2.000 m): II (EN 61010-1 / up to 5.000 m)

packaging type:

Box

permissible h2s contaminant concentration at a relative humidity 75:

10 ppm

permissible so2 contaminant concentration at a relative humidity 75:

25 ppm

pollution degree 5:

2 per EN 61010-1

power consumption 5 v system supply:

2.5 mA

protection type:

IP20

rated surge voltage:

5.0 kV (EN 60870-2-1 / Class VW3): 4.0 kV (UL 508): 4.0 kV (EN 61010-1 to 2000 m): 2.5 kV (EN 61010-1 to 5000 m)

relative humidity with condensation:

Short-term condensation per Class 3K7/IEC EN 60721-3-3 and E-DIN 40046-721-3 (except for wind-driven precipitation, water and ice formation)

relative humidity without condensation:

0.95

sensor connection:

2 x (2-wire)

shock resistance:

Per IEC 60068-2-27 (15g/11 ms/half-sine/1,000 shocks: 25g/6 ms/1,000 shocks), EN 50155, EN 61373

signal type:

Voltage

solid conductor:

0.25 2.5 mm / 24 14 AWG

strip length:

8 9 mm / 0.31 0.35 inch

supply voltage field:

60 VDC (-25 +30 %): via power jumper contacts (power supply via blade contact: transmission via spring contact)

supply voltage sensor:

60 VDC

supply voltage system:

5 VDC: via data contacts

surrounding air temperature operation:

-40 70 C

surrounding air temperature storage:

-40 85 C

total number of channels module:

2

vibration resistance:

Per IEC 60068-2-6 (acceleration: 5g), EN 60870-2-2, IEC 60721-3-1, -3, EN 50155: EN 61373

voltage range for signal 0:

7.5 +12 VDC

voltage range for signal 1:

44 78 VDC

voltage signal type:

60 VDC

weight:

46.500 g

width:

12 mm / 0.472 inch
