Wago 757-264/000-010
- SKU:
- 757-264/000-010
- Condition:
- New
- bending radius:
- 10 x cable diameter (min.) for flexible application
- cable design:
- Wire cross-section: 0.34 mm: Wire cross-section 2: 1 mm
- connection technology inputs outputs:
- 6 x M12 socket: 4-pole: incl. ground
- connection technology trunk cable:
- 1 x Fixed connecting cable
- contact resistance max:
- 0.01
- country of origin sales organisation germany:
- DE
- depth:
- 123 mm / 4.843 inch
- encapsulation:
- Fully encapsulated with conformal coating (UL 94 V0)
- halogen free:
- Yes
- height:
- 26 mm / 1.024 inch
- housing material:
- PA 66 (UL 94 V0): RAL 7035: silicon and halogen free
- indicators:
- LED (A) yellow: Signal status (1 x per contact): LED (U) green: Sensor/actuator box status
- insulation resistance:
- 1000 M
- length of connecting cable:
- 10 m
- material properties of the connections:
- Contact: CuSn, nickel base-coat plating and 0.8 m gold-plated: Threaded bush: die-cast Zn, nickel-plated: Seal: Viton: 50 mating cycles
- mounting type:
- Screw mount
- note on protection type:
- 72 h at a depth of 1 m under water per EN 60529 in the fully locked position with its plugs or protective caps
- packaging type:
- Box
- pollution degree 5:
- 3 per VDE 0110
- protection type:
- IP68
- rated value of electrical isolation:
- 500 V
- sheath material:
- PUR
- sheathed cable color:
- Black
- sheathed cable diameter:
- 7.8 mm
- shock resistance:
- Per IEC 60068-2-27
- signal characteristic:
- PNP
- strip length:
- 100 mm / 3.94 inch
- supply voltage:
- 10 30 VDC: Rated voltage: 32 V ~ rms
- surrounding air temperature operation:
- -25 80 C
- vibration resistance:
- Per IEC 60068-2-6
- width:
- 60 mm / 2.362 inch
- wire colors:
- White, green, yellow, gray, pink, red, green/yellow, brown, blue
