Radio antenna; with 2m cable and SMA plug; GSM/ UMTS/ LTE/ Bluetooth/ WLAN; 698-960, 1710-6000 MHz; 2G/3G/4G/5G.
The WAGO component serves as a replacement for the obsolete component 758-963 and is equivalent to the component 758974000001.
- cable type:
- CS29
- connector:
- SMA-Stecker
- country of origin sales organisation germany:
- CN
- fire load:
- 0.000 MJ
- frequency band:
- 617 960 MHz: 1710 6000 MHz
- gain:
- 617 960 MHz: 1dBi: 1710 2700 MHz: 4dBi: 3400 3800 MHz: 8dBi: 4900 6000 MHz: 9dBi
- length of connecting cable:
- 2 m
- mounting type:
- Wall mount
- packaging type:
- Bag
- protection type:
- IP66
- radio technology:
- GSM || UMTS || LTE || Bluetooth || WLAN || 5G
- surrounding air temperature operation:
- -40 85 C
- weight:
- 252.000 g
