Solid-state relay module; Nominal input voltage: 24 VDC; Output voltage range: 24
240 VAC; Limiting continuous current: 2 A; 2-wire connection; zero-cross switching; Yellow status indicator; Module width: 6 mm; gray.
The WAGO 857 series solid-state relay (SSR) features a plug-in input with a pre-assembled socket base and a yellow LED indicator. It supports a 2-wire connection and zero-cross switching, designed for single-pole, single-phase applications. The control voltage ranges from 20-28.8Vdc (24Vdc nominal), while the output rated voltage spans from 24Vac to 240Vac (230Vac nominal) with a continuous rated current of 2A. It includes Push-in CAGE CLAMP connections and is suitable for DIN-35 rail mounting with a 6mm width, offering IP20 protection and is equivalent to model 857714.
- color:
- Natural
- country of origin sales organisation germany:
- DE
- depth:
- 50 mm / 1.97 inch
- fire load:
- 0.038 MJ
- main product function:
- Operating tool
- number of pitches:
- 1 -way
- packaging type:
- Box
- pin spacing:
- 5/7.62 mm
- suitable:
- For male and female connectors with CAGE CLAMP connection
- weight:
- 1.350 g
