WAGO 857-734

(No reviews yet) Write a Review

Write a Review

×

WAGO 857-734

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

857-734

Condition:

New

circuit type:

2-wire connection

connection technology:

Push-in CAGE CLAMP

country of origin sales organisation germany:

CN

depth from upper edge of din rail:

81 mm / 3.189 inch

dielectric strength control load circuit ac 1 min:

3.51 kVrms

fine stranded conductor:

0.34 2.5 mm / 22 14 AWG

fire load:

0.000 MJ

height:

94 mm / 3.701 inch

input voltage range high level:

DC 16.8 30 V

input voltage range low level:

DC 0 4 V

insulation type between adjacent devices of the the same type:

Double insulation (safe isolation)

insulation type control load circuit:

None

insulation type to any type of adjacent devices:

Basic insulation

leakage current at rated voltage:

¤ 1 A

limiting continuous current:

8 A: 6 A (UL)

mounting type:

DIN-35 rail

nominal input current at un:

12 mA

nominal input voltage un:

DC 24 V (SELV)

nominal output voltage:

DC 24 V (SELV)

note:

Optocouplers and solid state relays are designed for use in signal processing networks, which are not supplied by the low-voltage power supply networks.

operating altitude max:

2000 m

output voltage range:

DC 1 30 V

overvoltage category:

II

packaging type:

Box

pollution degree:

2

power loss max pl max:

0.3 W

processing temperature:

-25 +50 C

protection type:

IP20

rated voltage:

300 V

relative humidity:

5 95 % (no condensation permissible)

safety information 1:

Adjacent devices are devices of the same design (series) that are arranged next to each other with the same orientation on the mounting rail. An end stop (249-116) must be fitted to devices of other types for compliance with the reinforced insulation

solid conductor:

0.34 2.5 mm / 22 14 AWG

standards specifications:

EN 61010-2-201 || EN 61373 || EN 61000-6-2 || EN 61000-6-3 || EN 50121-3-2 || EN 50121-4

status indicator:

Yellow LED

strip length:

9 10 mm / 0.35 0.39 inch

surrounding air operating temperature for ul:

-25 60 C

surrounding air temperature operation at un:

-25 70 C

surrounding air temperature storage:

-40 70 C

switching current min:

10 mA

switching frequency:

¤ 500 Hz

turn off time:

¤ 250 s

turn on time:

¤ 60 s

voltage drop at output max:

¤ DC 0.8 V

wago basic relay:

857-181

weight:

29.066 g

width:

6 mm / 0.236 inch
