4-conductor ground terminal block4 mm, green-yellow.
The WAGO 880 series ground/earthing terminal block is a green-yellow, single-deck unit designed for grounding/protective-earth applications. It features side and center marking slots and accommodates four wires using two clamps on each side. Suitable for wire sizes ranging from 0.08mm² to 4mm² or #28AWG to #12AWG, it utilizes CAGE CLAMP spring connections for secure and reliable connections. The terminal block mounts on a DIN-35 rail (35 x 15 / 35 x 7.5) and has a width of 5mm, equivalent to model 880837.
- actuation type:
- Operating tool
- color:
- Green-yellow
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 29 mm / 1.142 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 4 mm / 28 12 AWG
- fire load:
- 0.157 MJ
- flammability class per ul94:
- V0
- height:
- 87 mm / 3.425 inch
- insulation material:
- Polyamide (PA66)
- marking level:
- Center/side marking
- mounting type:
- DIN-35 rail
- packaging type:
- Box
- ratings per:
- IEC/EN 60947-7-2
- solid conductor:
- 0.08 4 mm / 28 12 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 14.284 g
- width:
- 5 mm / 0.197 inch
- wiring direction:
- Front-entry wiring
