Additional Information
actuation type: |
Slot screwdriver: (4 x 0.8) mm blade |
color: |
Beige |
connection technology: |
Screw-type connection |
country of origin sales organisation germany: |
DE |
fine stranded conductor: |
0.2 10 mm / 22 8 AWG |
fine stranded conductor with insulated ferrule: |
0.2 6 mm / 22 10 AWG |
fire load: |
0.000 MJ |
flammability class per ul94: |
V0 |
insulation material: |
Polyamide (PA66) |
legend ratings: |
(III / 3) Overvoltage category III / Pollution degree 3 |
nominal cross section: |
6 mm |
nominal voltage iii 3: |
1000 V |
packaging type: |
Bag |
rated current: |
41 A |
rated current 2: |
57 A |
rated surge voltage iii 3: |
8 kV |
solid conductor: |
0.2 10 mm / 22 8 AWG |
stranded conductor: |
0.2 10 mm / 24 8 AWG |
strip length: |
10 mm / 0.39 inch |
tightening torque: |
1.2 2 Nm |
weight: |
7.215 g |
