Zebra DXRTAC0G0RYZ00 Aurora Design Assistant 9+ Runtime License - IA, Advanced OCR, GMF

The Zebra DXRTAC0G0RYZ00 is an Aurora Design Assistant 9+ run-time license key that activates a vision project to execute on a deployed target platform. This part number bundles IA, Advanced OCR, GMF, Registration, Metrology, and Industrial Communication - a combination suited to inspection cells that need to locate, measure, and report to a PLC over EtherNet/IP, PROFINET, or Modbus TCP.

Run-time licenses are required on every production target - smart camera, vision controller, or PC - that runs an Aurora Design Assistant project outside the design environment. The 9+ designation indicates this license tier is forward-compatible with current and next-generation Aurora Design Assistant features beyond the original DA 9 release.

What's included in this license

DXRTAC0G0RYZ00 unlocks the following Aurora Design Assistant 9+ feature modules on the target platform:

Where this license is typically deployed

The IA, Advanced OCR, GMF combination targets inspection cells matched to that module set. Common deployments include:

• Pharmaceutical and medical device label OCR - lot/expiry code verification on cartons, vials, and blister packs.
• Automotive part marking - reading dot-peen and laser-etched alphanumeric part numbers for traceability.
• Robot guidance and bin picking support - locating parts in fixture-free environments using sub-pixel geometric pattern matching.

Compatible target platforms

Aurora Design Assistant 9+ run-time licenses activate on any Aurora-compatible target running the matching DA 9+ run-time environment:

• Zebra Iris GTX and Iris GTR smart cameras
• Zebra 4Sight EV7 and EV6 vision controllers
• Zebra XV7 and XV6 vision controllers
• Third-party Windows PCs with CoaXPress, GigE Vision, or USB3 Vision cameras when paired with a Zebra frame grabber and the Aurora run-time environment

Choosing the right Aurora Design Assistant license

Aurora Design Assistant 9+ run-time licenses are sold as module bundles. The part number encodes which feature modules are unlocked. If you're unsure whether DXRTAC0G0RYZ00 is the right SKU for your application, consider:

• Reading printed text? Advanced OCR is included - covers dot-peen, laser etch, date/lot codes, and low-contrast print.
• Locating parts before inspecting them? GMF + Registration handle that with sub-pixel pattern matching.
• Building from analysis primitives? IA gives you the foundational toolkit - filtering, morphology, blob analysis.
• Not on this SKU: Codec (barcode/2D code reading and grading), EF (edge-based measurement), ID (defect detection / CNN classification), MV (machine vision base package). If your application needs any of these, a different Aurora Design Assistant 9+ part number is required.

Automation Distribution is an authorized Zebra distributor for the full Aurora Design Assistant license catalog. If DXRTAC0G0RYZ00 doesn't match the modules you need, our team can map your application requirements to the correct part number the first time - call 1-888-600-3080 or use the contact form below.

At-a-glance specifications

Frequently asked questions

What is the difference between Aurora Design Assistant 9 and Aurora Design Assistant 9+?

Aurora Design Assistant 9+ is the forward-compatible license tier that extends the original DA 9 release. The "+" designation indicates compatibility with DA 9 and newer feature releases on the same run-time environment, so a 9+ key remains valid as Zebra ships incremental updates to the DA 9 generation. Existing DA 9 licenses without the "+" are tied to the specific feature set at original release.

Does this license include OCR for printed text?

Yes. DXRTAC0G0RYZ00 includes Advanced OCR - Zebra's deep-learning-based character recognition module for stressed text including dot-peen, laser etch, low-contrast print, and pharmaceutical date/lot codes. Note: this SKU does not include Codec, so 1D/2D barcode reading and grading is not part of this license.

Does this license include 3D image acquisition or CNN classification?

This SKU does not include the 3D acquisition module or the full IA/ID deep-learning toolset unless those modules are listed in the included modules table above. Specifically, DXRTAC0G0RYZ00 does not include: Codec (barcode/2D code reading and grading), EF (edge-based measurement), ID (defect detection / CNN classification), MV (machine vision base package). If your application requires any of these, a higher-tier Aurora Design Assistant 9+ part number is required.

What target platforms does this license work on?

Any platform that runs the Aurora Design Assistant 9+ run-time environment - including Zebra Iris GTX/GTR smart cameras, Zebra 4Sight EV7/EV6 vision controllers, Zebra XV7/XV6 vision controllers, and qualified third-party Windows PCs paired with a Zebra frame grabber.

Is this a single-seat license, or can it be moved between targets?

DXRTAC0G0RYZ00 is a single-platform run-time license bound to one target platform fingerprint. It is not designed to be moved between platforms after activation. For applications that need a portable license, the USB hardware key version of this module bundle (a separate part number ending in "U") provides that flexibility.

How does this license connect to a PLC?

The Industrial Communication module included with this SKU exposes inspection results, decoded data, and project tags over EtherNet/IP, PROFINET, Modbus TCP, and OPC UA. These are configured directly inside the Aurora Design Assistant project - no external middleware required.

Where can I get help selecting the right Aurora Design Assistant license?

Automation Distribution is an authorized Zebra distributor and can map your application requirements (what you need to read, locate, measure, and report) to the correct Aurora Design Assistant 9+ part number. Call 1-888-600-3080, use the contact form, or browse the full Aurora Design Assistant license catalog.

Zebra and Aurora are trademarks of Zebra Technologies Corporation. Module names reflect Zebra's published Aurora Design Assistant license module taxonomy.
