Zebra DXRTM2J202B200 Aurora Design Assistant 9+ Run-Time License, Full MV Toolset

Zebra Aurora Design Assistant 9+ Run-Time License, Full Toolset (DXRTM2J202B200)

The Zebra DXRTM2J202B200 is a run-time license key for Aurora Design Assistant (formerly Matrox Design Assistant), Zebra's flowchart-based integrated development environment for machine vision. This license activates a finished vision application on a target platform and covers a comprehensive set of tools: Machine Vision, Identification, Advanced OCR, Codec, Geometric Model Finder, Edge Finder, Registration, 3D, Metrology, Color Analysis, Industrial Communication, and Classification. It applies to Aurora Design Assistant version 9 and later.

Included Toolsets

• Machine Vision (MV): core tools for locating, measuring, and verifying parts, including presence and absence checks
• Identification (ID): reading and verifying 1D barcodes, 2D Data Matrix, and QR codes
• Advanced OCR: reading and verifying printed or marked text and characters
• Codec: compressing, archiving, and retrieving inspection images
• Geometric Model Finder (GMF): edge-based pattern location that finds and orients parts even when rotated, scaled, or partially hidden
• Edge Finder (EF): edge detection and extraction for locating features and boundaries
• Registration: aligning images to a reference to correct position and orientation before inspection
• 3D: acquiring and analyzing 3D data for height, volume, and profile measurement
• Metrology: precise geometric measurement and tolerancing of distances, angles, and diameters
• Color Analysis: color matching, identification, and segmentation
• Industrial Communication: data exchange with PLCs and factory systems over industrial protocols
• Classification: deep-learning classification for sorting or grading parts by learned appearance

Run-Time vs. Design-Time

A run-time license deploys and runs a finished Aurora Design Assistant project on a target platform, such as a Zebra smart camera, a Zebra vision controller, or a third-party PC with a compatible CoaXPress, GigE Vision, or USB3 Vision camera. The design-time environment used to build the project is licensed separately.

License Details

• Aurora Design Assistant version 9 and later
• Run-time (deployment) license, sold per license
• Export classification: EAR99

Applications

Deploying inspection, gauging, code reading, OCR, 3D measurement, color verification, and deep-learning classification applications built in Aurora Design Assistant onto production-line hardware.
