ABB AL9-30-10-80 ab al9301080 al9,3p contr,12vdc,1no

(No reviews yet) Write a Review
SKU:
AL9-30-10-80
Condition:
New
QN-QUOTE-REQUEST:
true
  • ABB AL9-30-10-80 ab al9301080 al9,3p contr,12vdc,1no
  • ABB AL9-30-10-80 ab al9301080 al9,3p contr,12vdc,1no
$253.08

Description

Overview

ABB

AC Non-Reversing IEC Contactors, A Series

Item# AL9-30-10-80 - Contactor, 3-P N/O, 12VDC Coil, Includes 1NO Aux Contact

A Series Information
  • 24~600 VAC/VDC Coils
  • Up to 450 HP @ 240V
  • Up to 900 HP @ 480V
  • UL; CSA Approved
  • Up to 1650 Amps
A-Line contactors are mainly used for controlling 3-phase motors and for controlling power circuits corresponding to their operating characteristics up to 690 and even 1000 VAC and 440 VDC. A variety of accessories are available for top or side-mount versions.

  • 3 or 4 Poles
  • Touch Safe Design
  • Easy Maintenance of Contacts and Coil Inspection

Specifications

Item Number:
AL9-30-10-80
UPC:
662019092676
Brand:
ABB
Item Category:
Contactors
Subcategory:
AC Non-Reversing IEC
Series:
A
Coil Voltage:
12 VDC
Coil Type:
Magnetic
Poles:
3NO
Frame Size:
AL9
Auxiliary Contacts:
1NO
Termination:
Screw
Overload Relays:
E16DU; TA25DU
General Purpose (AC1):
21 Amps
UL Motor Switching (AC3):
9 Amps
Max HP 200/208V 3PH:
2 Horsepower
Max HP 230/240V 3PH:
2 Horsepower
Max HP 460/480V 3PH:
5 Horsepower
Max HP 575/600V 3PH:
7.5 Horsepower
H x W x D:
3.07 in x 1.73 in x 3.82 in
  Net Weight:
1 lb 3 oz
  Gross Weight:
1 lb
