Description
Overview
ABB
General Purpose Transformers, T Series
Item# TC3050F - TRANSFORMER, 50VA, 1-PH, OPEN PRI: 380V, SEC: 24V, CE MARK LESS FUSECLIPS, TOUCHSAFE TERMINALS
T Series Information
- 45~5000 va
- Multple Primary AC Voltages
- 24/120 Volts AC Secondaries
- Epoxy Encapsulated Coils
- UL E175311
- Available with Terminal Covers through 750 va.
- Fuse Blocks Included on Some Models
- CE Compliance on Some Models
- Molded-in Terminals
Specifications
Item Number:
TC3050F
UPC:
662019687056
Brand:
ABB
Item Category:
Transformers
Subcategory:
General Purpose Transformers
Series:
T
Type:
Control
Phase:
1
VA Rating:
50 Volt-Amps
Primary Voltage:
380
Secondary Voltage:
24
Enclosed:
No
Primary Fuseholder:
Not Available
Secondary Fuseholder:
Not Available
Termination:
Integrally Molded Terminal Blocks
Terminal Covers:
Yes
Insulation Class:
105
Temperature Rise (F):
131 Degrees F
Comments:
Fuses and fuse holders sold separately. IP20 touch safe covers included.
Circuit Diag. No.:
ABBG_XFMR_TC3F_50-750
Diag. No.:
ABBG_XFMR_TC3_380_24
Picture No.:
ABBG_XFMR_TC
H x W x D:
3 in x 3 in x 3.25 in
Net Weight:
1 lb
Gross Weight:
1 lb
