Datasensing AK1/AP-3A8R Sensors

The Datasensing AK1/AP-3A8R Inductive Sensor is a high-performance M18 shielded sensor designed for precision and reliability. With a nominal sensing distance of 8mm and an operating range of 0 to 6.48mm, this sensor is ideal for detecting standard targets of 24x24mm FE360. It features a PNP output type with a normally open (NO) function, ensuring efficient proximity detection. The sensor operates at a switching frequency of 300Hz and supports an operating voltage range of 10 to 30Vdc. Constructed with a durable nickel-plated brass housing and an active head made of PBT, the sensor is built to withstand harsh environments, offering mechanical protection rated at IP67. It is equipped with a 10m PVC cable for flexible installation and includes two M18x1 nuts for secure mounting. The sensor's design incorporates short-circuit, reverse polarity, and impulsive overvoltage protection, making it a reliable choice for industrial applications. Additional features include a yellow LED indicator for output state, a low no-load supply current of ? 20mA, and a load current capacity of ? 400mA. The sensor's performance is further enhanced by its low thermal drift of Sr (< 10%) and repeat accuracy of < 5% at 24V and 23°C ±5°C. It is compatible with various materials, offering correction factors for copper (0.40), aluminium (0.45), brass (0.50), and stainless steel (0.75). The sensor is CE and UR approved, ensuring compliance with international standards, and is designed to withstand shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27.
