Datasensing FAI8/BN-2A Sensors
Datasensing
$111.34
The Datasensing FAI8/BN-2A Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a 90° diffuse reflection principle, these sensors offer a nominal sensing distance of 800mm, making them ideal for long-distance applications. The sensors are equipped with an NPN NO+NC output type, providing both normally open and normally closed functions for versatile integration.
Constructed with a robust PBT/PC housing, the FAI8/BN-2A sensors are built to withstand harsh environments, boasting an IP67 protection degree against dust and water ingress. The sensors operate efficiently within a wide voltage range of 10
30VDC and are protected against short circuits, overvoltage, and reverse polarity, ensuring durability and longevity.
With a high switching frequency of 250Hz and a rapid response time of 2ms, these sensors are perfect for fast-paced industrial applications. The sensitivity can be easily adjusted using a trimmer, allowing for precise calibration to suit specific needs. The sensors are also equipped with LED indicators for clear status visibility.
Designed to handle extreme conditions, the FAI8/BN-2A sensors operate within a temperature range of -25°C to +70°C and are resistant to shocks and vibrations as per IEC standards. The package includes M18 x 1 nuts and a screwdriver for easy installation. CE and cULus listed, these sensors meet international safety and performance standards, making them a reliable choice for various industrial applications.
- Nominal sensing distance:
- 800mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Notes:
- white target Kodak 90% 400 x 400mm
- Optic position:
- Radial 90°
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 50g
- Housing Material:
- PBT/ PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
- User Manuals:
- View
