Datasensing FALD/BP-2A Sensors
Datasensing
$112.33
The Datasensing FALD/BP-2A Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a 90° radial optic position, these sensors utilize a visible red laser emission to achieve a nominal sensing distance of up to 50 meters. With a robust PNP NO+NC output type, they offer both normally open and normally closed functions, ensuring versatile application compatibility.
Constructed with a durable plastic housing and a 2-meter axial cable, the FALD/BP-2A sensors are engineered to withstand harsh environments, boasting an IP67 protection degree. This ensures total protection against dust and water ingress, making them suitable for a wide range of industrial settings. The sensors are equipped with a sensitivity adjustment trimmer, allowing for precise calibration to meet specific operational needs.
Operating within a voltage range of 10 to 30 VDC, these sensors maintain a low no-load supply current of ? 25mA and a load current of ?100mA, ensuring energy efficiency. They feature a high switching frequency of 1kHz and a rapid response time of 500µs, making them ideal for fast-paced applications. The sensors are designed with comprehensive protection features, including short-circuit, overvoltage, and reverse polarity protection, ensuring reliable performance and longevity.
The FALD/BP-2A sensors are CE and cULus listed, meeting stringent safety and quality standards. They are also EMC compatible with EN 60947-5-2, ensuring minimal interference with other electronic devices. Supplied with M18 x 1 nuts and a screwdriver, these sensors are easy to install and integrate into existing systems. With a compact M18 x 1/L=78.5mm dimension and a lightweight design of 50g, they offer a seamless fit for various applications.
- Nominal sensing distance:
- 50m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Radial 90°
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 50g
- Housing Material:
- PBT/ PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- Glass / PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 15°C + 55° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 15°C...+ 55°C (Without freeze)
- Mechanical Protection:
- IP67
