Datasensing FAR2/BN-1A Sensors
Datasensing
$72.28
The Datasensing FAR2/BN-1A Sensors are high-performance photoelectric sensors designed for precise detection tasks. Featuring an axial diffuse reflection principle, these sensors offer a nominal sensing distance of 100mm, making them ideal for short-distance applications. With a robust M18 nickel-plated brass housing, they ensure durability and reliability in various industrial environments. The sensors operate on a 10...30 VDC power supply and provide NPN NO+NC output functions, allowing for versatile integration into existing systems.
Equipped with a 2m PVC cable, the FAR2/BN-1A sensors are easy to install and maintain. They boast a high switching frequency of 250Hz and a rapid response time of 2ms, ensuring quick and accurate detection. The sensors are protected against short circuits, overvoltage, and reverse polarity, offering total protection against electrical damages.
With an IP67 protection degree, these sensors are resistant to dust and water, making them suitable for harsh environments. The red LED emission at 660nm and sensitivity adjustment features enhance their adaptability to different detection needs. Additionally, the sensors are CE and cULus listed, ensuring compliance with international safety standards.
Ideal for applications requiring reliable and precise sensing, the Datasensing FAR2/BN-1A Sensors are a dependable choice for industrial automation and control systems.
- Nominal sensing distance:
- 100mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 130g
- Housing Material:
- Nickel plated brass / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
