Datasensing FARS/BN-0E Sensors
Datasensing
$141.63
The Datasensing FARS/BN-0E Sensors offer a comprehensive solution for precise object detection with their M18 design and versatile features. These sensors operate on a 10...30 Vdc power supply and are available in both axial and radial optic configurations with a flat surface. They are particularly effective for detecting transparent objects, thanks to their retro-reflective models with red emission. With an IP67 protection degree, these sensors are built to withstand harsh environments, featuring metallic or plastic housing options.
The FARS/BN-0E Sensors come equipped with sensitivity adjustment via a trimmer, allowing for fine-tuning to suit specific applications. They boast a nominal sensing distance of 130mm and a minimum sensing distance (blind zone) of 30mm, with a thermal drift of Sr at ?10% Sr and a repeat accuracy of 5%. The sensors utilize a background suppression function principle and have an optic position of axial.
Output options include NPN NO+NC, with a switching frequency of 1Khz and a response time of 500µs. They are designed to handle a load current of up to 100mA, with a no-load supply current of ? 25mA and a leakage current of ?10?A. The output voltage drop is minimal at ?2V@Iload=100mA, and they feature short-circuit protection with autoreset, overvoltage, and reverse polarity protection.
The sensors are equipped with LED indicators for easy status monitoring and are resistant to external light interference up to 5000lux (incandescent lamp) and 10000lux (sunlight). They are compact, with dimensions of M18 x 1 /L =79.4mm, and lightweight at 30g. The housing is made from durable PBT with a PC plug, and the active head material is PMMA.
These sensors are designed to operate in temperatures ranging from -25°C to +70°C without freezing, and they come with supplied accessories, including M18 x 1 nuts and a screwdriver. They are CE and cULus approved, ensuring compliance with international standards, and offer excellent EMC compatibility and mechanical protection against shocks and vibrations.
- Nominal sensing distance:
- 130mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Minimum sensing distance (blind zone):
- 30mm
- Function Principle:
- Blackground suppression
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Dimensions:
- M18 x 1 /L =79,4mm
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Dimensions:
- M18 x 1 /L =81,6mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
