Datasensing MSP/00-1E Sensors
Datasensing
$143.88
The Datasensing MSP/00-1E Sensors are advanced photoelectric sensors designed for precision and reliability in various industrial applications. Featuring a polarized function principle, these sensors offer a nominal sensing distance of 3.5 meters, ensuring accurate detection with minimal thermal drift of ?10% Sr. The sensors are equipped with a robust metal housing made of nickel-plated brass, providing durability and protection against electrical damage, with a degree of protection rated at IP67.
These sensors are versatile, offering a wide range of models including diffuse, retro-reflective, polarized, through-beam detection, and background suppression. The through-beam models boast a high sensing range, while the retro-reflective models utilize red visible polarized light for enhanced detection capabilities. The right-angle optic models (MP) and background suppression models with fixed distance add to the flexibility of the product line.
The MSP/00-1E Sensors are designed for ease of use, with selectable NPN/PNP and NO/NC output types, and a switching frequency of 80Hz. They feature a quick response time of 6.25ms and operate efficiently within a voltage range of 10 to 30VDC. The sensors are equipped with LED indicators for status output, and offer short-circuit and overvoltage protection, ensuring reliable performance in demanding environments.
With a compact design measuring M18 x 1 /L =93mm and weighing just 100g, these sensors are easy to install and integrate into existing systems. They are compatible with a wide range of operating temperatures from -25°C to +70°C, making them suitable for various industrial settings. The sensors also come with supplied accessories, including M18 x 1 nuts, for convenient installation.
Approved by CE and cURus, and compliant with EMC compatibility standards EN 60947-5-2, the Datasensing MSP/00-1E Sensors are a reliable choice for applications requiring high precision and durability.
- Nominal sensing distance:
- 3,5m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable NO/NC Selectable
- Output Function:
- NO/NC Selectable
- Switching frequency:
- 80Hz
- Response time:
- 6,25ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Impulsive Overvoltage Protection
- Weight:
- 100g
- Housing Material:
- Nickel plated brass / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Operating temperature:
- 25°C..+ 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
