Datasensing QXC/A0-1A Sensors

The Datasensing QXC/A0-1A Sensors are designed for precision and reliability in various industrial applications. Featuring a photoelectric sensor with a retroreflective function, these sensors offer a nominal sensing distance of 5 meters and an axial optic position. The device is equipped with two LED indicators for threshold and signal margin, providing clear visibility with a red light in retro-reflective, polarized, and through-beam models. With a fast response time of 0.75-0.5 ms and a high switching frequency of 750Hz, the QXC/A0-1A ensures quick and accurate detection. The sensor's output is NPN/PNP selectable with a normally open (NO) function, supporting a high output current of over 300 mA. It operates efficiently within a voltage range of 10 to 30VDC, with a low no-load supply current of ? 20mA and a minimal output voltage drop of ?1.2V at a 100mA load. Built to withstand challenging environments, the sensor is housed in durable ABS material with an IP65 degree of protection, ensuring resistance to dust and water. It is also equipped with short-circuit and reverse polarity protection, enhancing its durability and reliability. The sensor can operate in temperatures ranging from -25°C to +70°C without freezing, making it suitable for various industrial settings. The QXC/A0-1A comes with a 2-meter PVC cable for easy installation and includes ST70 mounting brackets and screws. Its compact cubic design, with dimensions of 15x23x40 mm and a weight of 70g, allows for easy integration into existing systems. The sensor is CE approved and complies with EMC compatibility standards EN 60947-5-2, ensuring it meets high safety and performance standards.
