Datasensing QXC/A0-1F Sensors
Datasensing
$193.82
The Datasensing QXC/A0-1F Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a retroreflective function with a nominal sensing distance of 5 meters, these sensors are equipped with axial optics and a trimmer for sensitivity adjustment, ensuring accurate detection in various applications. The sensors offer selectable NPN/PNP output types with a normally open (NO) function, providing flexibility in integration. With a fast response time of 666µs and a high switching frequency of 750Hz, they are ideal for high-speed operations.
The sensors are built to withstand challenging environments, with an operating temperature range of -25°C to +70°C and a robust IP65-rated housing made from durable ABS material. The compact cubic design, measuring 15x23x40mm, includes an M8 plug 4-pin connection for easy installation. The active head is crafted from acrylic, enhancing durability and performance.
Additional features include two LED indicators for output status and stability, short-circuit and reverse polarity protection, and a high output current capability of over 300mA. The sensors are CE approved and comply with EMC compatibility standards EN 60947-5-2, ensuring reliable operation in industrial settings. Supplied with ST70 mounting brackets and screws, the Datasensing QXC/A0-1F Sensors are a versatile and dependable choice for your sensing needs.
- Nominal sensing distance:
- 5m
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Retro-reflector
- Optic position:
- Axial
- Output type:
- NPN/PNP Selectable NO
- Output Function:
- NO
- Switching frequency:
- 750Hz
- Response time:
- 666µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?300mA
- Leakage current:
- ? 100?A @ 30Vdc
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red(output status) , Geen (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Dimensions:
- 15x23x54
- Weight:
- 70g
- Connections:
- M8 plug 4pin
- Active Head Material:
- Acrylic
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Material:
- ABS
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST70 mounting brakets and screws
- Dimensions:
- 15x23x40
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
